| Laser |
405 nm |
violet |
| Filters |
450/40 |
Brilliant Violet (BV) 421, Pacific Blue, DAPI |
| |
510/50 |
BV510, AmCyan, BD Horizon V500 |
| |
610/20 |
BV605, Qdot 605 |
| |
650/20 |
BV650, Qdot 655 |
| |
710/50 |
BV711, Qdot 705 |
| |
|
|
| Laser |
488 nm |
blue |
| Filters |
488/10 |
SSC |
| |
530/30 |
FITC, Alexa Fluor (AF) 488, GFP, YFP, CFSE |
| |
586/15 |
Phycoerythrin (PE), PI |
| |
695/40 |
PE-Cy5, PerCP, PerCP-Cy5.5, 7-AAD |
| |
|
|
| Laser |
561 nm |
yellow-green |
| Filters |
582/15 |
PE, DS-Red, AF546 |
| |
616/23 |
mCherry, PE-TexasRed, RFP, AF568, PI |
| |
780/60 |
PE-Cy7 |
| |
|
|
| Laser |
640 nm |
red |
| Filters |
660/20 |
Allophycocyanin (APC), AF647 |
| |
730/45 |
AF680, AF700 |
| |
780/60 |
APC-Cy7, APC-AF750 |
