| Laser |
405 nm |
violet |
| Filters |
450/45 |
Brilliant Violet (BV) 421, Pacific Blue, BD Horizon 450 |
| |
525/40 |
BV510, AmCyan, BD Horizon V500 |
| |
610/20 |
VBV605, Qdot 605 |
| |
660/10 |
BV650, Qdot 655 |
| |
780/60 |
BV786, Qdot 800 (optional in place of one of the above filters) |
| |
|
|
| Laser |
488 nm |
blue |
| Filters |
488/8 |
SSC |
| |
525/40 |
FITC, Alexa Fluor (AF) 488, GFP, YFP, CFSE |
| |
690/50 |
PE-Cy5, PerCP, PerCP-Cy5.5, 7-AAD |
| |
|
|
| Laser |
561 nm |
yellow-green |
| |
585/42 |
PE, DS-Red, AF546 |
| |
610/20 |
mCherry, PE-TexasRed, RFP, AF568, PI |
| |
690/50 |
Pe-Cy5 |
| |
780/60 |
Pe-Cy7 |
| |
|
|
| Laser |
638 nm |
red |
| |
660/10 |
Allophycocyanin (APC), AF647 |
| |
712/25 |
AF680, AF700 |
| |
780/60 |
APC-Cy7, APC-AF750 |
